DRIVERS

LRS-100-24V

meanwell

TECHNICAL

Driver IP
IP20
Dimming
Non-dimming
Application
24v LED strip

PARAMETERS

Model
LRS-50-1
Input voltage
AC85-264V
Output voltage
DC12V
Rated current
8.5A
Size
129*97*30mm
Other info
Non water-proof\Non-dimming\CCC UL TUV EAC CB CE certification\Overcurrent and Overvoltage Protection\Metal reticulated housing\Outline
  • Universal AC input / Full range
  • Withstand 300VAC surge input for 5 seconds
  • No load power comsumptiom<0.2W
  • Miniature size and 1 U low profile
  • High operating temperature up to 70°C
  • Protections: Short circuit / Overload / Over voltage
  • Cooling by free air convection
  • Compliance to IEC/BS EN/EN 60335-1 (PD3) and IEC/BS EN/EN61558-1, -2-16 for household
    appliances
  • 3 years warranty
  • Industrial automation machinery
  • Industrial control system
  • Mechanical and electrical equipment
  • Electronic instruments, equipment or apparatus
  • Household Appliances
LRS series is a single-output enclosed type power supply with 30mm of low profile design. Adopting the full range 85~264VAC input, the entire series provides an output voltage line of 3.3V, 5V, 12V, 15V, 24V, 36V and 48V.
In addition to the high efficiency up to 90%, the design of metallic mesh case enhances the heat dissipation. The whole series operates from -30°C through 70°C under air convection without a fan. Delivering an extremely low no load power consumption (less than 0.2W), it allows the end system to easily meet the worldwide energy requirement. LRS series has the complete protection functions and 5G anti-vibration capability; it is complied with the international safety regulations such as TUV BS EN/EN62368-1, BS EN/EN60335-1, BS EN/EN61558-1/-2-16, UL62368-1 and GB4943. LRS series serves as a high price-to-performance power supply solution for various industrial applications
